DETAIL SPESIFIKASI ISUZU
DIMENSI
| Panjang Keseluruhan | 5,710 | (mm) |
| Lebar Keseluruhan | 2,584 | (mm) |
| Tinggi Keseluruhan | 2,720 | (mm) |
| Jarak Terendah | 245 | (mm) |
| Jarak Poros Roda | 3,230 | (mm) |
| Jarak Pijak Roda Depan | 1,990 | (mm) |
| Jarak Pijak Roda Belakang | 1,790 | (mm) |
| Seating Capacity | – | (person) |
| Front Axle Capacity | 5,550 | (kg) |
| Rear Axle Capacity | 8,450 | (kg) |
MESIN
| Model/Tipe | 4HK1-TCS | |
| Sistem injeksi bahan bakar | 4 Cyl, OHC, Direct Injection Diesel | |
| Isi silinder | 5,193 (cc) | |
| Tenaga maksimum | 210/2600 (PS/rpm) | |
| Torsi maksimum | 65/1600-2600 (Kgm/rpm) | |
| Garis tengah x langkah | 115×125 (mm) | |
| Radius Putar | 5.6 m (m) |
VELG
| Ban Depan | Single, 9.00-20-14PR (Miler) | |
| Ban Belakang | Double, 9.00-20-14PR (Miler) | |
| Velg |
LAIN - LAIN
| Seat belt | Ada | |
| Accu | 12 – 65 x 2 | (V-AH) |
| Alternator | 24 – 50 | (V-A) |
| Kapasitas Tangki | 200 | (liter) |
| Max. Gradeability | 17 | (%) |
| Max. Speed | 107 | (Km/h) |
| Clutch Diameter | – | (mm) |
BERAT
| Curb Weight (berat kosong) | 4,680 | (kg) |
| Gross Vehicle Weight (berat total) | 28,000 | (kg) |
TRANSMISI
| Model | MZW6P/ In House Isz | |
| C | ||
| gigi 1 | 6.615 | |
| gigi 2 | 4.095 | |
| gigi 3 | 2.358 | |
| gigi 4 | 1.531 | |
| gigi 5 | 1.000 | |
| gigi 6 | 0.722 | |
| gigi 7 | ||
| gigi 8 | ||
| gigi 9 | ||
| Rev | 6.615 | |
| Final Gear Ratio | 6.500 |
REM
| Service brake | – | |
| Parking brake | – | |
| Exhaust brake | – | |
| Control Rem | – |
SUSPENSI
| Depan | – | |
| Belakang | – |
